Follow up visit ,within one year from date of installation, for inspection of the test rig, maintenance, additional training. Includes travel and living expenses for one technician. For up to 5 days, including travel time.

This is a research test rig designed to meet the requirements of ISO 20763-2004 except with a Connestoga pump housing replacing the Vickers housing that accommodates the V



- 104C cartridge. These cartridges, made by Connestoga are available through Falex Corporation. Includes the following: Test Stand made from 2 inch square carbon steel tubing for rigidity and painted with an two-part epoxy coating . See Appendix 1,attached to this quoatation, for a schematic of the test stand, All hydraulics for running the test are included, see Appendix 2, attached to the quotation, for details of the hydraulic layout. Includes the power control cabinet complete with controls, signal conditioners and displays Safety cut-off are included for fluid level, pressure loss and high temperature limit. Data Acquisition Logger System Operators manual in pdf format and will include operator instructions, circuits, diagrams, and component literature. One week on-site at IITC, Hyderabad, for a US techinician to assist in installation and set-up and training. Power supply details to be submitted by user
